Product Name
MAG FORGE 112R
Support MB Form Factor
ATX / M-ATX / ITX
Dimensions (W) x (D) x (H)
409 x 214 x 485 mm / 16.1 x 8.43 x 19.9 inches
Dimensions w/o Feet/Protrusions/Screws (DxWxH)
376 x 210 x 464 mm / 14.8 x 8.27 x 18.27 inches
I/O Ports
2x USB 3.2 Gen1 Type-A / 1 x Audio / 1 x Mic
Driver Bays
3x 2.5" / 2x 2.5" or 3.5"
VGA Card Support
330mm / 13 inches
CPU Cooler Support
160mm / 6.3 inches
Power Supply
Standard ATX, max up to 200mm (without 3.5" HDD tray installed)
Cooling Layout
Front: 120mm x 3 or 140mm x 2
Top: 120mm x 2 or 140mm x 2
Rear: 120mm x 1
Radiator Layout
Front: 120 / 140 / 240 mm
Top: 120 / 240 mm
Rear: 120 mm
